Photographs, high-speed frames and videos from the lab and the workshop: raindrops striking water, CO₂ sinking through a tank, particles steered inside drops by electric fields, water drops on cold and hot plates, smoke through a fan, and a small hatchback rebuilt as a hybrid.

A drop released from 20 cm: impact, the crater at 0.02 s, the water column at 0.15 s, and a droplet falling back at 0.19 s. From Verma et al. (2023). Raindrops
Video
The water column rising after a drop lands on fresh water, in slow motion. Raindrops
Video
The same impact on saltwater: a shorter column. Raindrops
Video
Impact on water with surfactant. Raindrops
Video
Impact on water with both salt and surfactant. Raindrops
Video
Laser-sheet video of the tracers after a drop lands on fresh water. Raindrops
Video
On saltwater, a wide particle-free gap opens along the interface. Raindrops
Video
With surfactant, the flow under the impact turns downward into a jet. Raindrops
PLIF in fresh water one minute after CO₂ enters the headspace: dark CO₂-rich water forms at the surface. CO₂ transfer
Ten minutes in, the CO₂-rich water has sunk in plumes toward the bottom of the tank. CO₂ transfer
Video
PLIF video: a plume of CO₂-rich water sinking from the surface. CO₂ transfer
A 180 µm water drop in corn oil with hollow glass particles, before the field is applied. Electric fields
The same drop after the field: the particles have gathered at the poles. Electric fields
A giant unilamellar vesicle filled with small particles. Electric fields
A particle-filled vesicle joined to its neighbors in a chain. Electric fields
A chain of vesicles of different sizes. Electric fields
Video
A water drop forming, landing on aluminum and evaporating, in silhouette. Contact angle
Water on aluminum at 13.6 °C, spread flat. Contact angle
Water on glass at 14.0 °C. Contact angle
Water beaded up on Teflon at 23.1 °C. Contact angle
Video
Incense smoke drawn through a 1-inch fan, filmed at 60 fps: the raw footage SmokeVel works from. Smoke velocimetry
One frame of the smoke test. Smoke velocimetry
Video
The same clip with SmokeVel’s speed map and flow arrows on top. Smoke velocimetry
The finished split hybrid with the team. Hybrid vehicle
The car’s original dead rear axle, before the conversion. Hybrid vehicle
The dead axle, removed. Hybrid vehicle
The live rear axle with its differential, before fitting. Hybrid vehicle
The live axle mounted under the car. Hybrid vehicle
An extra leaf added to the rear spring for the added weight. Hybrid vehicle
A rear brake drum. Hybrid vehicle
The drum brake backing plate with its lever and cable. Hybrid vehicle
